N40 Sintered NdFeB ring magnets for electronics

Price:	0.1 USD
Payment Terms:	T/T,L/C;PAYPAL
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: N40

Production Capacity: 1000Ton/Year

Delivery Date: Within 15days

Type: Permanent

Brand Name: Xingde

Hcb KA/m(KOe): >=836(>=10.5)

(BH)max KJ/m3(MGOe): 302-326(38-41)

Means of Transport: Ocean,Land,Air;express

Packing: Carton+Iron Pannel

Application: Speaker Magnet

Composite: Rare Earth Magnet

BrmT(KG): 1250-1280(12.5-12.8)

Hcj KA/m(KOe): >=955(>=12)

Max Working Tempreature: 80°C

Rare earth permanent magnets, ring shape with steady performance, are widely used in loudspeakers, speakers, headphone, earphone, cellphone, and so on

1, Description for N40 Sintered NdFeB ring magnet widely used in speaker

Ring magnets can be magnetized in different ways. The most common way is through the thickness and most of these are magnetized that way. I can also request an shape neodymium ring magnet to be magnetized through the diameter. Neodymium cannot be magnetized radially - with a pole on the outside edge and the opposite pole on the inside edge. However, if you really need neodymium ring magnets to have a radial magnetization pattern we can make them in arc segments that you can put together. Note: placing all the arc segments so that all north poles point in the same direction means that they all repel each other and will have to be held in place - usually with epoxy or CA glue.

2, Performance of N40 Sintered NdFeB ring magnet widely used in speaker

Product Name: Ring magnet
Place of Origin: Zhejiang, China (Mainland)
Application: Speakers, loudspeakers, headphone, earphone, Industry, Electronics, etc
Ring magnet
1. Materials: Rare earth magnet
2. Certification: ISO9001: 2008
3. Magnetic properties: High coercive force, (BH)max from 33 to 53MGOe, max working Temperature up to 230° C.
4. Grades: N35, N38, N40, N42, N45, N48, N50, 35M, 38M, 40M, 42M, 45M, 48M, 35H, 38H, 40H, 42H, 45H, 30SH, 33SH, 35SH. 38SH, 40SH, 42SH, 28UH, 30UH, 33UH, 35UH, 38UH, 28EH, 30EH, 33EH, 35EH etc
5. Shapes: Ring or produce many shapes according to your request, Block, Sphere, Disc, Ring, Segment, Cylinder, Sheet and so on.
6. Sizes: R x r x H x Degree as per your request
7. Coatings: Metallic Zinc, Nickel, Nickel+Nickel, Copper+Nickel, Nickel+copper+Nickel, Gold, Organic Epoxy, Nickel+Epoxy coating and so on;
8. Applications: Widely used in speakers, etc.
9. Parameters: Grade(property), Size(R x r x H x Degree) or Drawing, Coating, Quantity, etc.
10. Note: Our NdFeB arc magnet can produce as per your design, glad to give some suggestions if you need.
We provide a huge selection of Ring NdFeB Magnet commonly used in many speakers with high coercivity, low temperature.

Grade	Br		Hcj		BH(max)		Max Working temperature
Grade	KGs	T	Koe	KA/m	MGOe	KJ/m3	(Tw)
N52	1430-1480	14.3-14.8	>=11	>=876	50-53	398-422	80℃
N50	1400-1450	14.0-14.5	>=11	>=876	48-51	398-423	80℃
N48	1380-1420	13.8-14.2	>=12	>=955	46-49	366-390	80℃
N45	1320-1380	13.2-13.8	>=12	>=955	43-46	342-366	80℃
N42	1280-1320	12.8-13.2	>=12	>=955	40-43	318-342	80℃
N40	1250-1280	12.5-12.8	>=12	>=955	38-41	302-326	80℃
N38	1220-1250	12.2-12.5	>=12	>=955	36-39	287-310	80℃
N35	1170-1220	11.7-12.2	>=12	>=955	33-36	263-287	80℃

3, Picture of N40 Sintered NdFeB ring magnet widely used in speaker

Ningbo Xingde Magnet Co.,Ltd, locates in southern surburb of Ningbo, who is specialized in production of up-to-date magnetic material - NdFeB, and the technology development. Our company has advanced manufacturing process and test equipments, outstanding technologist of management and administration. Now with more than 3500 square meter workshop and nearly 200 staffs, we own the ability of annual production of over 1000 ton high performance sintered NdFeB magnets.
Our company was established in 1992, high corrective force and high induction. The company passed ISO9001:2008 quality management system certification. " Conscientiousness and responsibility makes the customers satisfactory." is the management aim of our enterprise.
Ningbo Xingde Magnet Co.,Ltd would offer various NdFeB magnetic products with high quality and competitive price sincerely for each customer.
